OPA730 Series
12 Watt Light Ring on
OptoTherm ? Linear Heat Spreader
OPA730 Series
?
?
?
?
?
12, 1 watt LEDs per ring
Mono-color per ring (Blue, Green, Red, Yellow, White)
Two component beam angle options (120° or 40°)
Universal connector (Tyco 2-292173-2 mates with 173977-2)
RoHS Compliant
OPA730_
Product Photo Here
OPA730_D
The OPA730 Series are designed for areas where light output and reliability are essential. The light beam angles
of 40° and 120° are ideal for illuminating small an d medium size areas while requiring minimal space.
A High Performance Heat Spreader (HPHS) is used to ensure the best heat dissipation of any light assembly in
the industry.
OptoTherm ? is designed to be the optimum material for distribution of heat for high power devices.
For custom colors and design contact your OPTEK representative.
Electrical / Optical Characteristics: T A =25°C, I F =700mA
Part Number
OPA730Y
OPA730B
OPA730G
OPA730R
OPA730W
OPA730YD
OPA730BD
OPA730GD
OPA730RD
OPA730WD
Typical Forward Voltage (V)
15.0
21.6
21.6
15.0
21.6
15.0
21.6
21.6
15.0
21.6
Luminous Flux (lm)
420
108
576
312
576
420
108
576
312
576
Beam Angle
120°
40°
Color
Yellow
Blue
Green
Red
White
Yellow
Blue
Green
Red
White
Dominant Wavelength
587 nm
470nm
530 nm
625 nm
6500°K
587 nm
470 nm
530 nm
625 nm
6500°K
RoHS
DO NOT LOOK DIRECTLY
AT LED WITH UNSHIELDED
EYES OR DAMAGE TO
RETINA MAY OCCUR.
OPTEK reserves the right to make changes at any time in order to improve design and to supply the best product possible.
OPTEK Technology Inc. — 1645 Wallace Drive, Carrollton, Texas 75006
Phone: (972) 323-2200 or (800) 341-4747 FAX: (972) 323-2396 visibleLED@optekinc.com www.optekinc.com
Issue B
01/2012
Page 1 of 2
